We make technology effective

Great ideas work thanks to small processes That is why we take care of every stage of project that we realize. Use our know-how that has been accumulated for years.

We will create key elements of your product as well as the entire device, which will meet your expectations and we guarantee satisfaction for a long time. We support customers in the phase of design, production, testing and programming and we are responsible for building the entire logistics chain.
A wide range of services: engineering support from the beginning of the project, purchase of components, printed circuit board assembly in lead-free and leaded technology, cover assembly, own PCB manufacturer (TS-PCB), applying protective coatings and pouring, optical control, testing, labeling, packing, direct deliveries to any place in the world.
A wide range of services: engineering support from the beginning of the project, purchase of components, printed circuit board assembly in lead-free and leaded technology, cover assembly, applying protective coatings and pouring, optical control, testing, labeling, packing, direct deliveries to any place in the world.

Production profile:

prototypes, High Mix Low Volume, mass production.

Production capacities:

3 SMT lines, over 100 THT positions.

Additional production capacities:

180 million SMD components and 3 million PTH components per month.

Delivery time:

10-15 business days.

maszyny

SMT

TSTRONIC has three SMT assembly lines with the following specifications.

  • ASYS BLO 03 Automatic PCB Feeder
  • PCB cleaning device - Teknek
  • DEK Horizon 03iX silkscreen printer
  • automatic soldering paste inspection system (SPI) KOH YOUNG KY8030-2
  • ASYS TRM 01 PCB conveyor
  • Pick&Place SIPLACE SIPLACE SX 2 automatic (2xCPP)
  • Pick&Place SIPLACE SIPLACE SX 1 automatic (1xCPP)
  • Pick&Place SIPLACE SIPLACE SX 2 + WPC (1xCPP, 1xTH)
  • ASYS TRM 02 PCB conveyor
  • reflow soldering oven Vitronics Soltec MR 933+
  • ASYS TRM 02 PCB conveyor
  • PERUN buffer - Multifunction Buffer
  • automatic Optical Control 3D (AOI) system - KOH YOUNG Zenith
  • automatic optical control system (AOI) - Nordson YesTech YTV-FX
  • verification station Nutek NTM530WSL-1500-3
  • ASYS BUL 03 Automatic PCB Receiver

THT

TSTRONIC have three THT assembly lines, we offer wave and selective assembly, please find specification below.

THT I
  • 6 - 12 workplaces of assembly
  • ERSA NWAVE-400 wave soldering unit - lead-free technology
THT II
  • 5 - 10 assembly stations
  • ERSA POWERFLOW e N2 wave soldering unit - lead-free technology
THS I
  • 3 - 6 assembly stations
  • ERSA VERSAFLOW 3/45 selective soldering unit - lead and lead-free technology
  • ASYS TRM 03 PCBN conveyor
dodatkowo
  • 48 workstations for manual assembly
  • 10 stations for preparing components for manual assembly (PTH)
maszyny3

Mechanical Assembly

MECH-01
  • 5 mechanical assembly stations
MECH-02
  • 5 mechanical assembly stations
MECH-03
  • 20 mechanical assembly/test/programming stations
MECH-04
  • 24 mechanical assembly/test/programming stations
maszyny4

Testing

  • 12 functional test stations
  • testing station with needle tester
  • BST test station
  • programming stations
  • 3 statistical control stations
  • optical verification station - Magnus HD microscope
  • optical verification station - KEYENCE VHX-5000 microscope

Others

maszyny5
  • X-ray inspection X-Ray Dage Ruby FP
  • BGA rework device - ERSA I550A Plus
  • BGA rework device - ERSA HR600
  • heating cabinet (MSD)
  • component storage cabinet (MSD)
  • vacuum packaging station (MSD)
  • testing and calibration station for feeders
  • accessories from WELLER, ERSA, OKI, METCAL
  • PressFit press - Tyco Electronics BMEP-5T
  • climate test chamber
  • automatic device for stencil washing KOLB PS300
  • automatic device for soldering frames washing KOLB AQUBE-MH711
  • ultrasonic cleaner for mechanical parts ULTRON U-100C
  • soldering paste mixer
  • ICT tester - SEICA
  • APCOM one/two component potting device
  • industrial printer for enclosures REAJET
  • Zortrax M300 3D printer
  • access control system to the EPA area
